Pneumatic cutting machine, Ø 0 - 45 mm

	CUT-P 7	CUT-P 12	CUT-P 20	CUT-P 30	CUT-P 30	CUT-P 30 tandem	CUT-P 45 tandem	CUT-P 45 3-cylinder	CUT-P 45 4-cylinder	CUT-P 45 Tandem	CUT-P 45 3-cylinder	CUT-P 45 4-cylinder
Item number	10100	10102	10103	10105	10105	10106	10274	10275	10276	10274	10275	10276
Compressed air connection	8 bar	8 bar	8 bar	6 bar	8 bar	8 bar	6 bar	6 bar	6 bar	8 bar	8 bar	8 bar
Weight	3 kg	3 kg	5 kg	5 kg	5 kg	10 kg	10 kg	11 kg	12 kg	10 kg	11 kg	12 kg
Dimensions (mm)	221 x 80 x 80	221 x 80 x 80	255 x 250 x 100	225 x 250 x 100	225 x 250 x 100	315 x 250 x 100	474 x 350 x 150	581 x 350 x 150	688 x 350 x 150	474 x 350 x 150	581 x 350 x 150	688 x 350 x 150
Max. Cutting diameter	0 - 7mm	0 - 12mm	0 - 20mm	0 - 30mm	0 - 30mm	0 - 30mm	0 - 45mm	0 - 45mm	0 - 45mm	0 - 45mm	0 - 45mm	0 - 45mm
Wire example
NYM-wire *	1 x 1,5	5 x 1,5	4 x 10	4 x 10	4 x 25	4 x 25	4 x 35	4 x 35	4 x 35	4 x 35	4 x 35	4 x 35
AWG *	Max AWG 12	Max AWG 8	Max AWG 6	Max AWG 6	Max AWG 4	Max AWG 4	Max AWG 2	Max AWG 1	Max AWG 1	Max AWG 2	Max AWG 1	Max AWG 0
Earting cable / Nominal cross section *	Max 25mm²	Max 30mm²	Max 50mm²	Max 80mm²	Max 90mm²	Max 120mm²	Max 150mm²	Max 185mm²	Max 240mm²	Max 185mm²	Max 240mm²	Max 400mm²
Steel cable / diameter* **	Max 3mm	Max 4mm	Max 6mm	Max 6mm	Max 8mm	Max 10mm	Max 10mm	Max 12mm	Max 14mm	Max 12mm	Max 14mm	Max 16mm
* Values under reserve. Every wire has different compositions (CU-part, coat size,shield part,....). ** For steel cable you need a shear blade.
