ARG450-ARG1200
Uncoiler ARG450-1200
- E-mail us, we reply swiftly!
- Invoice
- Questions? Call us +46 708-14 76 00 kl 07.30-16:30 (UTC +1) Mon-Fri
Description
Article no.: ARG450-ARG1200
Uncoiler with stand and overflow protection, Max 700 kg
The uncoiling device is designed to hold coils of plastic or metallic hoses,
such as corrugated pipes, insulation pipes, hydraulic or compressed air hoses and similar materials, up to a maximum coil weight of 30 kg. The device can also be used for thin cable coils.
The internally ball-bearing rotating plate enables easy material removal, while the surrounding 200 mm high winding protection effectively prevents layers from falling off the rotating plate.
An integrated brake reduces the overrunning of the rotating plate after sudden tightening by a processing machine.
| Feature | ARG450 | ARG600 | ARG800 | ARG1000 | ARG1200 |
|---|---|---|---|---|---|
| Outer diameter | 76 cm | 76 cm | 96 cm | 116 cm | 136 cm |
| Total height Floor version/table version |
120 cm / 57 cm | — | — | — | 120 cm |
| Dispenser height Floor version/table version |
86 cm / 23 cm | — | — | — | 86 cm |
| Total height incl. wheels (optional) | plus 7.5 cm | — | — | — | — |
| Turntable diameter | 450 mm | 600 mm | 800 mm | 1000 mm | 1200 mm |
| Coil core diameter | 130–210 mm | 130–380 mm | 200–650 mm | 230–800 mm | 230–800 mm |
| Device weight Floor version/table version |
22 kg / 17 kg | 25 kg / 21 kg | 30 kg / 26 kg | 40 kg / 36 kg | 50 kg |
| Maximum coil weight | 15 kg | 30 kg | — | — | — |
| Number of adjustable bolts | 3 | 6 | 6 | 6 | 6 |
