Ändhylsor, Isolerade,  för kablar med tjock isolering 0.5 - 16 mm²

Ändhylsor, Isolerade, för kablar med tjock isolering 0.5 - 16 mm²

Läs mer...
  • Maila oss, vi svarar snabbt!
  • Faktura
  • • 0708-14 76 00 • Mån-Fre • kl. 07.30-16:30
  • Min. order 500 kr ex. moms.
  • Frakt från 95kr

Beskrivning

Art.nr: GLW_WireEndSleeves-Insulated-ForWiresWithThickInsulation

Ändhylsor, Isolerade, 0.14 - 150 mm²

FärgkoderStandardfärger enligt DIN 46228 T4, T-standard, W-standard
MaterialE-Cu / Polypropylen
SurfaceTin plated
Min. Thickness3 µm
Max. Temp105°C
UL confirm toolingCAP 4
CertificatesUL
REACH/RoHSConfirmed
Tvärsnitt (mm²)Längd (mm)FärgTypBeskrivning
0.58WHA00555GBfor wires with thick insulation (GB)
0.58OGA00557GBfor wires with thick insulation (GB)
0.510WHA00575GBfor wires with thick insulation (GB)
0.510OGA00577GBfor wires with thick insulation (GB)
0.512OGA00587GBfor wires with thick insulation (GB)
0.512WHA00585GBfor wires with thick insulation (GB)
0.758LBUA00752GBfor wires with thick insulation (GB)
0.758GYA00755GBfor wires with thick insulation (GB)
0.758WHA00757GBfor wires with thick insulation (GB)
0.7510LBUA00772GBBfor wires with thick insulation (GB)
0.7510GYA00775GBfor wires with thick insulation (GB)
0.7510WHA00777GBfor wires with thick insulation (GB)
0.7512GYA00785GBfor wires with thick insulation (GB)
0.7512LBUA00782GBfor wires with thick insulation (GB)
0.7512WHA00787GBfor wires with thick insulation (GB)
18RDA01055GBfor wires with thick insulation (GB)
18YEA01057GBfor wires with thick insulation (GB)
110RDA01075GBfor wires with thick insulation (GB)
110YEA01077GBfor wires with thick insulation (GB)
112RDA01085GBfor wires with thick insulation (GB)
112YEA01087GBfor wires with thick insulation (GB)
1.56BKA01535GBfor wires with thick insulation (GB)
1.56RDA01537GBfor wires with thick insulation (GB)
1.58BKA01555GBfor wires with thick insulation (GB)
1.58RDA01557GBfor wires with thick insulation (GB)
1.510BKA01575GBfor wires with thick insulation (GB)
1.510RDA01577GBfor wires with thick insulation (GB)
2.58GYA02552GBfor wires with thick insulation (GB)
2.58BUA02555GBfor wires with thick insulation (GB)
2.510GYA02562GBfor wires with thick insulation (GB)
2.510BUA02565GBfor wires with thick insulation (GB)
2.512GYA02582GBfor wires with thick insulation (GB)
2.512BUA02585GBfor wires with thick insulation (GB)
410GYA04055GBfor wires with thick insulation (GB)
412GYA04075GBfor wires with thick insulation (GB)
612YEA06055GBfor wires with thick insulation (GB)
1612WHA16052GBfor wires with thick insulation (GB)
1612BUA16055GBfor wires with thick insulation (GB)
1612GNA16057GBfor wires with thick insulation (GB)
1618WHA16082GBfor wires with thick insulation (GB)
1618BUA16085GBfor wires with thick insulation (GB)
1618GNA16087GBfor wires with thick insulation (GB)
