Hot marking unit RM200
Värmepräglare RM200
- Maila oss, vi svarar snabbt!
- Faktura
- • 0708-14 76 00 • Mån-Fre • kl. 07.30-16:30
- Min. order 500 kr ex. moms.
- Frakt från 95kr
Beskrivning
Art.nr: LOE_RM200
| Power supply | 115 VAC, 230 VAC, 50-60 Hz, max. 200 VA |
| Compressed air supply | 0.7 MPa (7 bar / 90 psi) |
| Heating control | Closed loop temperature control, 0 - 160 °C |
| Cable Ø minimum | 2.0 mm |
| Cable Ø maximum | 20.0 mm |
| Width of stamp form | 2 - 20 mm |
| Production rate | app. 1.0 seconds per stamping action (depends upon dwell time) |
| Foil type | Several qualities and colors |
| Foil widths | 2 pieces of 25 mm x 120 m |
| Foil consumption | Continuously variable up to 25mm |
| Measurements Control unit( mm) | 385 x 225 x 75 |
| Measurements Marking unit, (open), (mm) | 420 x 420 x 420 |
| Measurements Marking unit, (closed), (mm) | 165 x 420 x 420 |
| Weight Control unit | 6 kg (13.2 lbs) |
| Weight Marking unit | 13 kg (28.6 lbs) |
| Noise level | < 70 dB (A) |
